1.電阻resistance

10-4～1×105Ω

2.電阻率范圍Resistivity

10-4～1×105Ω-cm

3.電導率Conductivity

5×10-5～104s/cm

4.測試電流范圍 current

1μA，10μA，100μA，1mA，10mA，

5.測量電壓量程Voltage

測量電壓量程 voltage：2mV  20mV 200mV 2V

測量精度Accuracy±（0.1%讀數）

分辨率 Resolution：  0.1uV  1uV  10uV  100uV

6.電流精度Current

±0.3% Accuracy

7.電阻精度Resistance Accuracy

≤0.5%標準電阻 standard resistance

8.顯示讀數display

液晶顯示：電阻值、電阻率、電導率值、溫度、壓強值、單位自動換算、橫截面、高度，上下限警報

LCD: resistance, resistivity, conductivity, temperature, pressure value, the unit automatically conversion, cross-section, height，Super and upper limit alarm

9.測試方式Test mode

四端測量法Four-terminal measurement method

10.傳感器壓力Pressure Sensors

200kg；(其他規格可以定制)

(Other specifications can be customized)

11.粉末測量裝置

Powder measuring device

模具Mold：內徑inner diameter 10mm； 20mm（選購）, height: 25mm,

加壓方式：手動液壓加壓測量 pressure: manual hydraulic pressure / automatic compression mode (purchase).

12.工作電源power supply

輸入: AC 220V±10% ,50Hz  功 耗Power consumption：<30W

13.外形尺寸/dimensions

主機Mainframe：約L330mm*D350mm*H120mm ;手動裝置about：約H450mm*L200mm*D120mm

14.凈重量/Net Weight

約35kg

About 35kg

15. 標配外選購Others buy

a.標準校準電阻1-5個；b.PC軟件一套；c.電腦和打印機依據客戶要求配置；d.計量證書1份 ，e. 高度校準塞規1個

a. Standard calibration resistor 1-5.     b.PC software 1 set

c. computers and printers based on customer configuration requirements.         d. Measurement certificate 1.

e. Height calibrated plug gauge 1 pcs
