BZGFWF標準型旋轉閥/關風機

● 適用于≤2kg/cm2系統壓力或壓差

● 能定量供料

● 法蘭標準DIN PN10 ANSl150lbs

● 設置排氣口 (正壓輸送時選用)將葉輪旋轉帶出的高壓氣體通過排   氣口送至排氣裝置，提高填充效率

● 軸承外置式安裝、經久耐用、性能優異

● 提供鏈驅動、直聯驅動多種安裝方式

● 根據需求配置減速機電機

● 材質主要有：碳鋼、鑄鋼、鑄鐵、不銹鋼系列等

BZGFWF

Pressure Range: ≤2 bar. system and different pressure

Main Material: Carbon Steel. Cast Steel, Stainless Steel

Drive Mode: Direct Drive/Chain Drive

Ffange Standard: DfN PN10 ANSf 150lbs

Specification:

1. Body vent opening (Applicable to Positive pressure conveying) high filling efficiency by integrated leakage gas venting.

2. Anti-Blocking design, Ensure safeclly start Even if the Rotary Valve full of material.

3. Outboard Bearing, iongllfe and Excellent performance.
