ZMF-1200C-M
直接聯系
安徽貝意克設備技術有限公司
安徽
面議
貝意克
ZMF-1200C-M
4691
Main features
主要特點
Heat insulating materials adopt Alumina fiber inorganic ones, which is formed with vacuum absorption, environmental protecting and energy saving.
保溫材料采用真空吸附成型的氧化鋁纖維無機材料，環保節能;
Furnace body is double air cooling structure to control furnace surface Temp. no more than 60℃ when furnace is heated into max. Temp.
爐體采用雙層風冷結構，爐子燒到**溫度時，殼體表面溫度低于60℃
Furnace body use super-light high alumina fiber material, with the features of low hot melt, flexible Temp. control and energy saving, etc.
爐體采用超輕質高鋁纖維材料，具有熱熔小，溫度升降控制靈活、節能等特點。
Mechanical pump and vacuum unit are optional according to vacuum degree requirement, very suitable for test and small batch production.
設備可根據真空度的需要分別選用機械泵或真空機組，非常適合于試驗和小批量生產之用。
Technical Parameters
技術參數
Power 輸入電源 | Power rated: 4.2KW (380±10%V) 額定功率：4.2KW (380±10%V) |
Voltage 電壓 | Voltage rated: AC 380±10%V 50/60Hz 額定電壓： AC 380±10%V 50/60Hz |
Working Temperature 工作溫度 | Max. Temperature: 1200℃ **溫度：1200℃ Continuous working temperature: ≤1000℃ 持續工作溫度：≤1000℃ Recommended Heating Rate: 15°C /min 推薦升溫速率：15℃/分 |
外觀 Surface | 主體白色 Mainly white |
Temperature Controller 控溫方式 | PID automatic control and auto-tune function. 模糊PID控制和自整定調節 30 programmable segments for precise thermal processing. 智能化30段可編程控制 Built-in protection for the over-heated and broken thermocouple. 超溫和斷偶報警功能 |
Thermocouple 熱電偶 | K type K型 |
Heating Elements 加熱元件 | Fe-Cr-Al Alloy doped by Mo 電阻絲（摻鉬鐵鉻鋁合金） |
Temperature Accuracy 控溫精度 | +/- 1℃ |
Dimensions 尺寸 | Chamber size(L*D*H): 250x300x250mm(18L) 腔體尺寸(長*深*高)：250x300x250mm(18L) Furnace size(L*W*H): 620x610x1070mm 爐子尺寸(長*寬*高)：620x610x1070mm |
Cold ultimate vacuum 冷態極限真空 | ≤100Pa |
Warranty 質保 | One year limited warranty with lifetime support (Such consumable parts as processing tubes, and O-rings are NOT supported by the warranty) 一年質保終身支持（消耗品如O型圈不在質保范圍內） |
Attention 注意事項 | The equipment is not sealed, and can not be put into toxic, harmful, inflammable and explosive gas. Can add the inlet port to pass through the inert gas or oxygen. 此設備腔體不密封，不能通入有毒有害，易燃易爆氣體。可以加裝進氣接頭，通惰性氣體或者氧氣 Small cracks may appear on the surface of the refractory ceramics over extended use. This is a normal occurrence and the cracks may be repaired with alumina coating. 在使用過程中爐膛表面可能出現細小裂紋。這是正常情況，裂紋可以用氧化鋁涂層修復。 You shall place the sample in to a crucible. Never place sample on the chamber bottom directly. 應該把樣品放進坩堝里。不要把樣品直接放在腔底。 |
Compliance 認證 | CE Certified CE認證 All electric components ( >24V) are UL / MET / CSA certified 所有電氣部件( >24V)都有UL / MET / CSA 認證 The furnace is ready to pass TUV(UL61010) or CSA certification at extra cost. 可付費進行TUV(UL61010)或CSA認證
|
Operation instructions 操作指導 | Click to download the operating manual 點擊下載說明書
|
